「外サイクロイド作ったなら次は内サイクロイドだよねー」
と言われた気がして。
前と同じく上バーが定円、下バーが動円。
どうやら定円 > 動円 > 0の関係があるらしいので、それらしくしておいた。
using UnityEngine; using System.Collections; public class MakeLine : MonoBehaviour { LineRenderer lR; //頂点の再計算フラグ bool recal = false; //Lineの頂点数 int vCount = 3600; //角回転量 float angle; #region Sliders value float v1 = 1.0f; float v2 = 1.0f; float v3 = 1.0f; float v4 = 1.0f; #endregion // Use this for initialization void Start () { this.Initialize(); } // Update is called once per frame void Update () { if (this.recal) { this.SetVertex(); this.recal = false; } } //初期化 private void Initialize() { this.angle = Mathf.PI / (90.0f-1.0f); this.lR = this.GetComponent<LineRenderer>(); this.lR.SetVertexCount(this.vCount); this.recal = true; } private void SetVertex() { float t1 = v1 - v2; float t2 = 10.0f; if (v2 != 0) t2 = (v1 - v2) / v2; for (int i = 0; i < this.vCount; i++) { float av = this.angle * i; float x = t1 * Mathf.Cos(av) + v2 * Mathf.Cos(t2 * av); float y = 1; float z = t1 * Mathf.Sin(av) - v2 * Mathf.Sin(t2 * av); x = x * 4.0f; z = z * 4.0f; this.lR.SetPosition(i, new Vector3(x, y, z)); } } #region Get sliders value //スライダーの値取得 public void getSlider1Value(float v) { v1 = v; this.recal = true; } public void getSlider2Value(float v) { v2 = v; this.recal = true; } public void getSlider3Value(float v) { v3 = v; this.recal = true; } public void getSlider4Value(float v) { v4 = v; this.recal = true; } #endregion }
